ABP2LANT010BG2A3XX
Inventory: 49
$16.88Details
Tech Specifications
| Description | Product Attribute |
|---|---|
| Manufacturer | Honeywell |
| Product Category | Board Mount Pressure Sensors |
| Pressure Type | Gauge |
| Operating Pressure | 0 bar to 10 bar |
| Accuracy | 0.25 % |
| Output Type | Digital |
| Mounting Style | SMD/SMT |
| Interface Type | I2C |
| Operating Supply Voltage | 3.3 V |
| Port Type | Single Axial Barbed |
| Resolution | 14 bit |
| Package / Case | 8.2 mm x 7.2 mm x 10.6 mm |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 110 C |
| Series | ABP2 |
| Packaging | Box |
| Operating Supply Current | 33.8 nA |
| Output Voltage | 1 V |
| Port Size | 2.74 mm x 7 mm |
| Product Type | Board Mount Pressure Sensors |
| Subcategory | Sensors |
| Supply Voltage - Max | 3.6 V |
| Supply Voltage - Min | 1.8 V |
