18CX10
Product Description
Honeywell MICRO SWITCH CX switches are built especially for outdoor use in hazardous atmospheres. These enclosures are constructed to withstand the pressure of an internal explosion. Flame paths cool the exploded gases to a point less than the lowest safe operating temperature of the surrounding gas.
The product's o-ring seals make the enclosure rain tight, but are outside of required flame paths so explosion proof requirements are maintained. Unless special ordered, all basic switches operate on clockwise and counterclockwise rotation. The actuating mechanism can be field adjusted for CW or CCW operation only. No tools are required.
Tech Specifications
| Description | Product Attribute |
|---|---|
| Manufacturer | Honeywell |
| Product Category | Basic / Snap Action Switches |
| Type | Micro Switch |
| Contact Form | SPDT |
| Current Rating | 4 mA to 20 mA |
| Voltage Rating DC | 40 VDC |
| Operating Force | 0.5 N |
| Termination Style | Screw |
| Mounting Style | Chassis Mount |
| IP Rating | IP66 |
| Illuminated | Non-Illuminated |
