1HS6
Inventory: 323
$170.9Details
Specifications
| Description | Product Attribute |
|---|---|
| Manufacturer | Honeywell |
| Product Category | Basic / Snap Action Switches |
| Type | Sealed |
| Contact Form | SPDT |
| Switch Function | ON - (OFF), OFF - (ON) |
| Actuator | Lever |
| Current Rating | 25 A |
| Voltage Rating AC | 125 VAC |
| Voltage Rating DC | 120 VDC |
| Operating Force | 22 oz to 28 oz |
| Termination Style | Screw |
| Mounting Style | Chassis Mount |
| Actuator Style | Lever |
| Illuminated | Non-Illuminated |
| Product Type | Snap Action Switches |
| Subcategory | Switches |
| Tradename | Microswitch |
